Electrical Characteristics
|
|
STC Power Rating Pmp (W)
|
130
|
|
Open Circuit Voltage Voc (V)
|
130.0
|
|
Short Circuit Current Isc (A)
|
1.59
|
|
Voltage at Maximim Power Vmp (V)
|
100.0
|
|
Current at Maximim Power Imp (A)
|
1.30
|
|
Panel Efficiency
|
8.3%
|
|
Fill Factor
|
62.9%
|
|
Power Tolerance
|
-3.00% ~ 3.00%
|
|
Maximum System Voltage Vmax (V)
|
600
|
|
Maximum Series Fuse Rating (A)
|
|
|
Temperature Coefficients
|
|
Temperature Coefficiency of Isc
|
0.060 %/ºC
|
|
Temperature Coefficiency of Voc
|
-0.32 %/ºC
|
|
Temperature Coefficiency of Pmp
|
-0.28 %/ºC
|
|
Mechanical Characteristics
|
|
Cell Type
|
Amorphous Thin-Film Tandem
|
|
Cell Size(mm)
|
1 × 1
|
|
Cells
|
0 × 0
|
|
Dimensions
|
1414.0 × 1114.0 × 35.0mm (43.9 × 55.7 × 1.4 inch)
|
|
Weight
|
21.0Kg (46.3 lbs)
|
|
Junction Box (Safety Rating, Bypass Diodes)
|
|
|
Positive Cable (Length, Cable Cross-Section)
|
|
|
Negative Cable (Length, Cable Cross-Section)
|
|
|
Plug Connector (Type, Safety)
|
|
|
Front Cover (Thickness,Material)
|
|
|
Backsheet Cover (Color, Thickness, Material)
|
|
|
Encapsulation Materials
|
|
|
Frame Material
|
|
|
Operation Conditions
|
|
Nominal Operating Cell Temperature (NOCT)
|
|
|
Operating Temperature
|
-40.0ºC to 85.0ºC
|
|
Maximum Load
|
|
|
Hail Storm Rating
|
|
|
Fire Safety Rating
|
|
|
Warranty & Certification
|
|
Certificates
|
- IEC 61730 Ed.2
- IEC 61646 Ed.2
|
|
Defects & Workmanship Warranty Period
|
5.0 Years
|
|
90% Power Output Warranty Period
|
10.0 Years
|
|
80% Power Output Warranty Period
|
25.0 Years
|
|
Are Warranties Insured By Third Party
|
False
|
MT130 Datasheet in English, Spanish and German
