Electrical Characteristics
|
|
STC Power Rating Pmp (W)
|
140
|
|
Open Circuit Voltage Voc (V)
|
22.1
|
|
Short Circuit Current Isc (A)
|
8.59
|
|
Voltage at Maximim Power Vmp (V)
|
18.4
|
|
Current at Maximim Power Imp (A)
|
7.63
|
|
Panel Efficiency
|
12.8%
|
|
Fill Factor
|
73.7%
|
|
Power Tolerance
|
0.00% ~ 2.50%
|
|
Maximum System Voltage Vmax (V)
|
1000
|
|
Maximum Series Fuse Rating (A)
|
20
|
|
Temperature Coefficients
|
|
Temperature Coefficiency of Isc
|
0.030 %/ºC
|
|
Temperature Coefficiency of Voc
|
-0.37 %/ºC
|
|
Temperature Coefficiency of Pmp
|
-0.50 %/ºC
|
|
Mechanical Characteristics
|
|
Cell Type
|
Monocrystalline Cell
|
|
Cell Size(mm)
|
156 × 156
|
|
Cells
|
4 × 9
|
|
Dimensions
|
1526.0 × 716.0 × 35.0mm (28.2 × 60.1 × 1.4 inch)
|
|
Weight
|
15.0Kg (33.1 lbs)
|
|
Junction Box (Safety Rating, Bypass Diodes)
|
|
|
Positive Cable (Length, Cable Cross-Section)
|
|
|
Negative Cable (Length, Cable Cross-Section)
|
|
|
Plug Connector (Type, Safety)
|
|
|
Front Cover (Thickness,Material)
|
|
|
Backsheet Cover (Color, Thickness, Material)
|
|
|
Encapsulation Materials
|
|
|
Frame Material
|
|
|
Operation Conditions
|
|
Nominal Operating Cell Temperature (NOCT)
|
45.0ºC
|
|
Operating Temperature
|
-40.0ºC to 85.0ºC
|
|
Maximum Load
|
2400
|
|
Hail Storm Rating
|
|
|
Fire Safety Rating
|
Class A
|
|
Warranty & Certification
|
|
Certificates
|
- CE Europe
- IEC 61215 Ed.2
- IEC 61730 Ed.2
|
|
Defects & Workmanship Warranty Period
|
5.0 Years
|
|
90% Power Output Warranty Period
|
12.0 Years
|
|
80% Power Output Warranty Period
|
25.0 Years
|
|
Are Warranties Insured By Third Party
|
False
|
