Electrical Characteristics
|
|
STC Power Rating Pmp (W)
|
205
|
|
PTC Power Rating Pmpp (W)
|
190.7
|
|
PTC/STC Power Ratio
|
93.0%
|
|
Open Circuit Voltage Voc (V)
|
68.8
|
|
Short Circuit Current Isc (A)
|
3.84
|
|
Voltage at Maximim Power Vmp (V)
|
56.7
|
|
Current at Maximim Power Imp (A)
|
3.62
|
|
Panel Efficiency
|
17.7%
|
|
Fill Factor
|
77.6%
|
|
Power Tolerance
|
0.00% ~ 10.00%
|
|
Maximum System Voltage Vmax (V)
|
600
|
|
Maximum Series Fuse Rating (A)
|
15
|
|
Temperature Coefficients
|
|
Temperature Coefficiency of Isc
|
0.035 %/ºC
|
|
Temperature Coefficiency of Voc
|
-0.28 %/ºC
|
|
Temperature Coefficiency of Pmp
|
-0.35 %/ºC
|
|
Mechanical Characteristics
|
|
Cell Type
|
HIT Silicon Cell
|
|
Cell Size(mm)
|
156 × 156
|
|
Cells
|
6 × 12
|
|
Dimensions
|
1319.0 × 880.0 × 46.0mm (34.6 × 51.9 × 1.8 inch)
|
|
Weight
|
15.0Kg (33.1 lbs)
|
|
Junction Box (Safety Rating, Bypass Diodes)
|
4 Bypass diodes
|
|
Positive Cable (Length, Cable Cross-Section)
|
780
|
|
Negative Cable (Length, Cable Cross-Section)
|
630
|
|
Plug Connector (Type, Safety)
|
MC4™ Locking Connectors
|
|
Front Cover (Thickness,Material)
|
|
|
Backsheet Cover (Color, Thickness, Material)
|
|
|
Encapsulation Materials
|
|
|
Frame Material
|
|
|
Operation Conditions
|
|
Nominal Operating Cell Temperature (NOCT)
|
46.0ºC
|
|
Operating Temperature
|
-20.0ºC to 46.0ºC
|
|
Maximum Load
|
2880
|
|
Hail Storm Rating
|
1" hailstone (25mm) at 52 mph (23m/s)
|
|
Fire Safety Rating
|
|
|
Warranty & Certification
|
|
Certificates
|
|
|
Defects & Workmanship Warranty Period
|
5.0 Years
|
|
90% Power Output Warranty Period
|
10.0 Years
|
|
80% Power Output Warranty Period
|
25.0 Years
|
|
Are Warranties Insured By Third Party
|
False
|
|
Packaging
|
|
Number of Panels per Box
|
34
|
|
Box Gross Size(mm)
|
1346 × 897 × 1952mm
|
|
Box Gross Weight
|
530.0Kg (1168.4 lbs)
|
|
Boxes per Pallet
|
1
|
|
Pallet Gross Size(mm)
|
|
|
Pallet Gross Weight
|
|
|
Shipping Loading (20GP)
|
|
|
Shipping Loading (40GP)
|
|
|
Shipping Loading (40HQ)
|
|
