Electrical Characteristics
|
|
STC Power Rating Pmp (W)
|
190
|
|
PTC Power Rating Pmpp (W)
|
176.4
|
|
PTC/STC Power Ratio
|
92.8%
|
|
Open Circuit Voltage Voc (V)
|
67.5
|
|
Short Circuit Current Isc (A)
|
3.75
|
|
Voltage at Maximim Power Vmp (V)
|
54.8
|
|
Current at Maximim Power Imp (A)
|
3.47
|
|
Panel Efficiency
|
16.4%
|
|
Fill Factor
|
75.1%
|
|
Power Tolerance
|
0.00% ~ 10.00%
|
|
Maximum System Voltage Vmax (V)
|
600
|
|
Maximum Series Fuse Rating (A)
|
15
|
|
Temperature Coefficients
|
|
Temperature Coefficiency of Isc
|
0.053 %/ºC
|
|
Temperature Coefficiency of Voc
|
-0.28 %/ºC
|
|
Temperature Coefficiency of Pmp
|
-0.35 %/ºC
|
|
Mechanical Characteristics
|
|
Cell Type
|
HIT Silicon Cell
|
|
Cell Size(mm)
|
0 × 0
|
|
Cells
|
8 × 12
|
|
Dimensions
|
1319.0 × 880.0 × 46.0mm (34.6 × 51.9 × 1.8 inch)
|
|
Weight
|
15.0Kg (33.1 lbs)
|
|
Junction Box (Safety Rating, Bypass Diodes)
|
IP67, 4
|
|
Positive Cable (Length, Cable Cross-Section)
|
630mm, 4mm
|
|
Negative Cable (Length, Cable Cross-Section)
|
780mm, 4mm
|
|
Plug Connector (Type, Safety)
|
MC4 Locking Connectors
|
|
Front Cover (Thickness,Material)
|
|
|
Backsheet Cover (Color, Thickness, Material)
|
|
|
Encapsulation Materials
|
|
|
Frame Material
|
|
|
Operation Conditions
|
|
Nominal Operating Cell Temperature (NOCT)
|
45.0ºC
|
|
Operating Temperature
|
-20.0ºC to 46.0ºC
|
|
Maximum Load
|
2880
|
|
Hail Storm Rating
|
1" hailstone (25mm) at 52 mph (23m/s)
|
|
Fire Safety Rating
|
Class C
|
|
Warranty & Certification
|
|
Certificates
|
|
|
Defects & Workmanship Warranty Period
|
5.0 Years
|
|
90% Power Output Warranty Period
|
10.0 Years
|
|
80% Power Output Warranty Period
|
20.0 Years
|
|
Are Warranties Insured By Third Party
|
False
|
|
Packaging
|
|
Number of Panels per Box
|
34
|
|
Box Gross Size(mm)
|
1346 × 897 × 1952
|
|
Box Gross Weight
|
530.0Kg (1168.4 lbs)
|
|
Boxes per Pallet
|
1
|
|
Pallet Gross Size(mm)
|
1346 × 897 × 1952
|
|
Pallet Gross Weight
|
530.0Kg (1168.4 lbs)
|
|
Shipping Loading (20GP)
|
10
|
|
Shipping Loading (40GP)
|
21
|
|
Shipping Loading (40HQ)
|
27
|
High Efficiency
HIT® Power solar panels are leaders in sunlight conversion efficiency. Obtain
maximum power within a fixed amount of space. Save money using fewer system
attachments and racking materials, and reduce costs by spending less time installing
per watt.
Power Guarantee
SANYO’s power ratings for HIT Power panels guarantee customers receive 100%
of the nameplate rated power (or more) at the time of purchase, enabling owners
to generate more kWh per rated watt, quicken investment returns, and help realize
complete customer satisfaction.
Temperature Performance
As temperatures rise, HIT Power solar panels produce 10% or more electricity
(kWh) than conventional crystalline silicon solar panels at the same temperature.
Proprietary Technology
HIT solar cells are hybrids of single crystalline silicon surrounded by ultra-thin
amorphous silicon layers, and are available solely from SANYO. HIT Power models
are ideal for grid-connected solar systems, areas with performance based incentives,
and renewable energy credits.
Structural Strength
HIT Power panels have a double-wall black anodized aluminum frame for extra
strength, and are tested to 60PSF. The panels come pre-equipped with a touchsafe
junction box, USE-2 outdoor rated cables, MC4™ locking connectors, and
are UL 1703 safety rated for wind, hail, and fire.
Valuable Features
HIT Power solar panels operate silently, have no moving parts and are among the
lightest per watt in the industry. Unique eco-packaging minimizes cardboard waste
at the job site. The packing density of the panels reduces transportation, fuel, and
storage costs per installed watt.
Quality Products
SANYO silicon wafers located inside HIT solar panels are made in California USA,
and the panels are assembled in an ISO 9001 (quality), 14001 (environment), and
18001 (safety) certified factory. The panels have a Limited 20-Year Power Output
and 5-Year Product Workmanship Warranty.
